CX series
CX20 PRO
Equipped with a 256 × 192 infrared detector, the CX20 series uses real-time AI super-resolution technology to enhance image resolution to 512 × 384. Featuring a 3.5-inch HD display, along with optional laser pointer and laser rangefinder, it enables precise fault location and significantly improves inspection efficiency.
Temperature range: Low temperature range: -20°C to 150°C; High temperature range: 100°C to 550°C.
Infrared resolution: 256 × 192 pixels.
Super resolution: 512 × 384 pixels.
Spectral range: 7.5 – 14 µm.
Pixel size: 12 µm.
Measurement accuracy: ±2% or ±2°C.
NETD: <40 mK.
FOV: 56° × 42°.
IFOV: 3.8 mrad.
Focal length: 3.2 mm.
Spatial resolution: 3.8 mrad.
Frame rate: 25 Hz.
Detector: Uncooled detector.
Display: 3.5-inch, 480 × 640.
Visible camera: 2 megapixels.
Viewing modes: Infrared, Fusion, PIP and Visible.
Laser: Integrated.
Software: PC and Mobile (iOS, Android).
Storage: 32 GB.
Communication protocols: USB, Wi-Fi.
Battery life: 6 hours.
Operating temperature: -10°C to +50°C.
Operating humidity: 10% to 95%.
Protection rating: IP54.
Weight: 500 g.
Dimensions: 246 × 101 × 85 mm.
IX2 series
IX2 Air Pro
The IX2 AIR Pro wireless thermal camera for smartphones is compatible with both Android and iOS devices, enabling wireless image transmission at distances of up to 30 metres. With a thermal image resolution of 256 × 192 pixels, it can achieve real-time AI super-resolution up to four times higher, reaching 512 × 384 pixels. Thanks to its adjustable 7 mm focus lens, it is capable of capturing high-definition images at close range. The AI Raya voice interaction feature allows users to configure parameters quickly and efficiently. It is suitable for industrial applications such as circuit board maintenance, electrical maintenance, equipment inspection and HVAC leak detection, helping to identify thermal risks with maximum efficiency.
Specifications:
Temperature range: -20°C to 550°C.
Infrared resolution: 256 × 192 pixels.
Spectral range: 7.5 – 14 µm.
Pixel size: 12 µm.
Measurement accuracy: ±2% or ±2°C.
NETD: <40 mK.
FOV: 25° × 19°.
IFOV: 1.71 mrad.
Focal length: 7 mm.
Frame rate: 25 Hz.
Detector: Uncooled detector.
Visible image: 2 megapixels.
Display: Images can only be viewed on your mobile device.
Software: PC and Mobile (iOS, Android).
Storage: Available storage on your mobile device.
Communication protocols: USB, Wi-Fi, Bluetooth.
Battery life: 2 hours.
Operating temperature: -10°C to +50°C.
Operating humidity: 10% to 95%.
Protection rating: IP54.
Weight: 142 g.
Dimensions: 136.2 × 41 × 29.3 mm.
RM series
RM320
Designed for precision, the RM320 integrates a 12 µm sensor that produces thermal images with a resolution of 384 × 288 pixels. Thanks to its thermal sensitivity of 35 mK, it can detect even the smallest temperature variations in complex environments. Its operating range extends up to 650°C, making it a versatile tool for predictive maintenance applications, from HVAC audits to the petrochemical industry.
Specifications:
Temperature range: Low temperature range: -20°C to 150°C; High temperature range: 100°C to 650°C.
Infrared resolution: 384 × 288 pixels.
Spectral range: 7.5 – 14 µm.
Pixel size: 12 µm.
Measurement accuracy: ±2% or ±2°C.
NETD: <35 mK (25°C, F1.0).
FOV: 27° × 20°.
IFOV: 1.31 mrad.
Focal length: 9.1 mm.
Frame rate: 30 Hz.
Detector: Uncooled.
Focus mode: Manual.
Charging method: USB-C or desktop charging dock.
Visible image: 5 megapixels.
Display: 3.5-inch, 640 × 480.
Software: PC and Mobile (iOS, Android).
Storage: 32 GB MicroSD card, expandable up to 512 GB.
Laser: Included.
Communication protocols: USB and Wi-Fi.
Batteries: 2.
Battery life: 6 hours (3 hours per battery).
Operating temperature: -10°C to +50°C.
Operating humidity: 10% to 95%.
Protection rating: IP54.
Weight: 683.5 g.
Dimensions: 258.4 × 105.1 × 102.3 mm.
RM620
The RM620 raises the standard of thermal inspection with a superior resolution of 640 × 512 pixels, powered by a 12 µm detector. This image density, combined with a thermal sensitivity of 35 mK, ensures exceptional clarity when detecting hot spots. With temperature measurement capabilities of up to 650°C, it is a robust solution for advanced analysis in photovoltaic plants and the design of highly complex electronic circuits.
Temperature range: Low temperature range: -20°C to 150°C; High temperature range: 100°C to 650°C.
Infrared resolution: 640 × 512 pixels.
Spectral range: 7.5 – 14 µm.
Pixel size: 12 µm.
Measurement accuracy: ±2% or ±2°C.
NETD: <35 mK (25°C, F1.0).
FOV: 29° × 18°.
IFOV: 1.31 mrad.
Focal length: 9.1 mm.
Frame rate: 30 Hz.
Detector: Uncooled.
Focus mode: Manual.
Charging method: USB-C or desktop charging dock.
Display: 3.5-inch, 640 × 480.
Visible image: 5 megapixels.
Software: PC and Mobile (iOS, Android).
Storage: 32 GB MicroSD card, expandable up to 512 GB.
Laser: Included.
Communication protocols: USB and Wi-Fi.
Batteries: 2.
Battery life: 6 hours (3 hours per battery).
Operating temperature: -10°C to +50°C.
Operating humidity: 10% to 95%.
Protection rating: IP54.
Weight: 680 g.
Dimensions: 258.4 × 105.1 × 102.3 mm.
RT series
RT400
Specifications:
Temperature range: -20°C to +150°C, 100°C to 650°C (optional: 400°C to 1500°C).
Infrared resolution: 480 × 360 pixels.
Super resolution: 960 × 720 pixels.
Spectral range: 7.5 – 14 µm.
Pixel size: 12 µm.
Measurement accuracy: ±2% or ±2°C, whichever is greater.
NETD: <35 mK (25°C, F1.0).
FOV: Standard lens: 25° × 20°; super telephoto lens: 7° × 5.6°; telephoto lens: 14° × 11.2°; wide-angle lens: 45° × 36°.
IFOV: Standard lens: 0.92 mrad; super telephoto lens: 0.27 mrad; telephoto lens: 0.52 mrad; wide-angle lens: 1.71 mrad.
Focal length: Standard lens: 17.7 mm; super telephoto lens: 60.9 mm; telephoto lens: 31.5 mm; wide-angle lens: 9.5 mm.
Frame rate: 25 Hz.
Detector: Uncooled infrared detector.
Focus mode: Manual, auto (one-touch), continuous auto, laser-assisted and electric micro-focus.
Charging method: USB-C or desktop charging dock.
Display: 5-inch OLED touchscreen, 1280 × 720 resolution.
Visible image: 13 megapixels.
Software: PC (Infrared Analysis) and Mobile Device (iOS, Android).
Storage: Standard 64 GB MicroSD card, expandable up to 2 TB.
Laser: Included.
Communication protocols: Wi-Fi, Bluetooth, USB, DP, Type-C to HDMI.
Battery: 1 field-replaceable 10,000 mAh lithium battery.
Battery life: ≥ 6 hours of continuous operation.
Operating temperature: -20°C to +55°C.
Operating humidity: 10% to 95% (non-condensing).
Protection rating: IP54.
Weight: Approximately 1.3 kg (including battery).
Dimensions: 144 × 129 × 307 mm.
RT630
Specifications:
Temperature range: -20°C to +150°C, 100°C to 650°C (optional: 400°C to 1500°C).
Infrared resolution: 640 × 512 pixels.
Super resolution: 1280 × 1024 pixels.
Spectral range: 7.5 – 14 µm.
Pixel size: 12 µm.
Measurement accuracy: ±2% or ±2°C, whichever is greater.
NETD: <35 mK (25°C, F1.0).
FOV: Standard lens: 25° × 20°; super telephoto lens: 7° × 5.6°; telephoto lens: 14° × 11.2°; wide-angle lens: 45° × 36°.
IFOV: Standard lens: 0.68 mrad; super telephoto lens: 0.20 mrad; telephoto lens: 0.38 mrad; wide-angle lens: 1.26 mrad.
Focal length: Standard lens: 17.7 mm; super telephoto lens: 60.9 mm; telephoto lens: 31.5 mm; wide-angle lens: 9.5 mm.
Frame rate: 25 Hz.
Detector: Uncooled infrared detector.
Focus mode: Manual, auto (one-touch), continuous auto, laser-assisted and electric micro-focus.
Charging method: USB-C or desktop charging dock.
Display: 5-inch OLED touchscreen, 1280 × 720 resolution.
RS series
RS600
Equipped with a new-generation 12 µm detector featuring a thermal sensitivity of just 25 mK, the RS600 delivers sharper and more detailed thermal images. Based on the Android operating system and integrated smart hardware, the device offers advanced features including trend analysis, a variable aperture lens, measurement across 25 points, lines and areas, image freeze, intelligent Electronic Image Stabilisation (EIS), a 5.5-inch touchscreen display, and more.
Specifications:
Temperature range: -20°C to +150°C, 100°C to 650°C; optional: 400°C to +1500°C.
Infrared resolution: 640 × 512 pixels.
Super resolution: 1280 × 1024 pixels.
Spectral range: 7.5 – 14 µm.
Pixel size: 12 µm.
Measurement accuracy: ±2% or ±2°C.
NETD: <25 mK (25°C, F1.0).
FOV: Standard lens: 25° × 20°; super telephoto lens: 7° × 5.6°; telephoto lens: 14° × 11.2°; wide-angle lens: 45° × 36°.
IFOV: Standard lens: 0.68 mrad; super telephoto lens: 0.20 mrad; telephoto lens: 0.38 mrad; wide-angle lens: 1.26 mrad.
Focal length: Standard lens: 17.7 mm; super telephoto lens: 60.9 mm; telephoto lens: 31.5 mm; wide-angle lens: 9.5 mm.
Frame rate: 25 Hz.
Detector: Uncooled.
Focus mode: Manual focus, one-button centre focus, automatic centre focus, one-touch autofocus, laser-assisted focus and electric micro-focus.
Charging method: USB-C or desktop charging dock.
Display: 5.5-inch touchscreen, 1820 × 1080 resolution.
Viewing modes: Infrared, Fusion, PIP and Visible.
Software: PC and Mobile (iOS, Android).
Storage: Standard 64 GB MicroSD card. Supports SD, SDHC and SDXC cards up to 2 TB.
Communication protocols: USB, Wi-Fi and Bluetooth.
Battery: 9000 mAh lithium-ion battery, field-replaceable, with fast charging.
Battery life: Continuous operating time ≥ 3 hours (depending on actual environment and operating conditions).
Operating temperature: -15°C to +50°C.
Operating humidity: 10% to 95%.
Protection rating: IP54.
Weight: 1.3 kg (including battery).
Dimensions: 278 × 116 × 113 mm.
RS1280
The RS1280 is Raythink’s first high-performance, ultra-high-resolution thermal camera, featuring a resolution of 1280 × 1024 pixels. Equipped with a new-generation in-house developed VOx infrared detector with a thermal sensitivity of just 25 mK, the device combines intelligent imaging algorithms with precise temperature measurement algorithms to deliver clearer infrared images and greater measurement accuracy. The Android operating system, smart applications and advanced features, together with a 5.5-inch adjustable-angle display and a rotating handle, provide an enhanced user experience that fully meets ergonomic requirements.
Specifications:
Temperature range: -20°C to +150°C, 150°C to 800°C; optional: 400°C to 2000°C.
Infrared resolution: 1280 × 1024 pixels.
Super resolution: 2560 × 2048 pixels.
Spectral range: 7.5 – 14 µm.
Pixel size: 12 µm.
Measurement accuracy: At an ambient temperature of 25°C, within the temperature measurement range of 5°C to 150°C, accuracy is ±1°C or ±1% of the reading (whichever is greater). At an ambient temperature of 25°C, for temperature measurement ranges below 1500°C, accuracy is ±2°C or ±2% of the reading.
NETD: <25 mK (25°C, F1.0).
FOV: Standard lens: 25° × 20°; telephoto lens: 12° × 9.6°; wide-angle lens: 45° × 36°.
IFOV: Standard lens: 0.34 mrad; telephoto lens: 0.17 mrad; wide-angle lens: 0.6 mrad.
Focal length: Standard lens: 34.9 mm; wide-angle lens: 19.8 mm; telephoto lens: 72.9 mm.
Frame rate: 30 Hz.
Detector: Uncooled.
Focus mode: Manual focus, one-button centre focus, automatic centre focus, one-touch autofocus, laser-assisted focus and electric micro-focus.
Charging method: USB-C or desktop charging dock.
Display: 5.5-inch touchscreen, 1920 × 1080 resolution.
Viewing modes: Infrared, Fusion, PIP and Visible.
Software: PC and Mobile (iOS, Android).
Storage: Standard 64 GB MicroSD card. Supports SD, SDHC and SDXC cards up to 2 TB.
Communication protocols: USB, Wi-Fi and Bluetooth.
Battery: 9000 mAh lithium-ion battery, field-replaceable, with fast charging.
Battery life: Continuous operating time ≥ 3 hours (depending on actual environment and operating conditions).
Operating temperature: -15°C to +50°C.
Operating humidity: 10% to 95%.
Protection rating: IP54.
Weight: 1.7 kg (including battery).
Dimensions: 140 × 210 × 115 mm.
